Snorkels and raised air intakes
Last reviewed
It gives the engine a better place to breathe from. It does not give the vehicle more ground under it.
What it actually is
A snorkel is a relocated intake, not a filter. The air still goes to the same air filter in the same airbox, and that filter still does all of the filtering. What changes is where the air is drawn from and, on some designs, what happens to it on the way.
Where the engine breathes from
An engine is an air pump. Everything it does depends on a clean, uninterrupted supply, and the standard intake sits low in the engine bay, which is the worst place on the vehicle to find one.
A snorkel moves that intake up and out. Higher up, the air is cleaner and less of whatever the vehicle is driving through gets drawn in. A cyclonic head then does real work on it before it reaches your filter: stators in the intake throat spin the incoming air, centrifugal force throws the heavier dust and water droplets to the outer wall, and extraction ports expel them.
That helps in dust, which is most of what you drive through in this part of the world. It helps in water, because the intake now sits well above the point the standard one would have been drawing from. And it helps on a long corrugated day, because a filter that is not choking is a filter the engine is not fighting.
Ram head or cyclonic head
Two shapes, and they do different jobs.
A ram head is an open, forward-facing scoop. Its function is elevation and direction. Anything that gets into it goes down the tube, and everything downstream is handled by the airbox and the filter.
A cyclonic or pre-cleaner head separates before the filter, as above. On dusty work it is the one that reduces what reaches the element, and on a vehicle that spends its life on gravel it is usually the better choice. Many heads can be rotated or swapped, so this is a decision you can revisit.
For gravel, the cyclonic head is the one that earns its keep.
Water: the part that gets people hurt
A snorkel changes one path in. Your real crossing depth is set by the lowest thing on the vehicle that cannot get wet, and most of those sit well below the top of the snorkel.
Check what your own manufacturer says. If there is a wading depth in your owner’s manual, that is your number, and fitting a snorkel does not raise it.
Safety
Walk the crossing first. Check the depth, the bottom and the exit. If you are not prepared to walk it, do not drive it. A bow wave held ahead of a slow vehicle is what keeps the engine bay clear, and that only works at walking pace.
What actually happens when an engine drinks
Water does not compress. If enough of it gets into a cylinder, the piston cannot complete its stroke and something has to give. At speed that typically means a bent or broken connecting rod, and from there a cracked block or a damaged crank. At idle the engine may simply stop, and it can sometimes be cleared by removing the plugs or injectors and turning the engine over to push the water out.
The rebuild is the reason people fit snorkels, and it is a fair reason. Just fit one understanding that it protects one path in, not the vehicle.
Getting it fitted, and what good looks like
A snorkel is a hole cut in your bodywork and a sealed path to your engine. The part in the box is the easy half.
The manufacturer's own installation instruction
- Safari’s installation guides state that it is the installer’s responsibility to ensure that all connections are water tight.
- On the drain valves specifically, Safari’s guidance is that they can permit water to enter the air intake, and that they should be sealed to ensure a watertight installation.
Source: Safari Snorkel published installation guides SS176HF and SS177HF.
That is the manufacturer putting the outcome on the fitment rather than on the product. The joint into the airbox, the seal where the body is cut, and the drain valve are where a snorkel either works or is decorative.
Five things worth checking
Whether it is being fitted for you or already on a vehicle you are buying, these are the five things that decide whether it works.
- 01The joint into the airbox. Sealed and clamped, with no gap. This single connection decides whether the snorkel does anything at all, and it is hidden under the bonnet where nobody looks.
- 02The original intake path. Ask whether it has been closed off. If the standard inlet is still open, the engine simply draws the easier air and the snorkel is decorative.
- 03The cut edge. Where the guard is cut, the bare metal must be treated and sealed. An untreated edge is a rust problem that shows up two years later, from the inside out.
- 04The drain valve. Safari’s own guidance is that drain valves can admit water and should be sealed. Ask what was done with yours.
- 05The fasteners, after the first trip. Corrugation works everything loose. A snorkel that was tight when it left the workshop should be checked again after the first proper gravel trip, and that goes for the roof rack and everything else you have bolted on.
Our fitment centre partners fit these every week. They will fit yours to the manufacturer’s instructions, to the applicable regulations and safety standards, and they will seal it properly, which is the part that actually determines whether it works.
So do you actually need one?
If you spend real time on gravel, in convoy, in the dust of the vehicle in front, the argument is a good one and it is about air quality and filter service rather than about crossings.
If you are buying it because of water, buy the understanding first. Find out what your vehicle’s breathers, ECU and fuse box heights actually are, find out whether your manufacturer publishes a wading depth, and be honest about how often you cross anything at all. Most people cross water a handful of times a year and drive through dust every single trip.
And whichever reason you land on, spend the money on the fitment rather than on the head.
FAQ
Frequently asked questions
Does a snorkel let me drive through deeper water?
No. It raises the air intake so the engine is less likely to draw water, but your wading depth is set by the lowest thing that cannot get wet: differential and gearbox breathers, the alternator, the ECU and fuse box, and the cabin intake. A snorkel changes one of those, not the rest.
Does a snorkel help with dust?
It helps the engine breathe, in dust and in water both. A cyclonic head spins the incoming air so centrifugal force throws dust and water droplets out of the stream before they reach your air filter, and the intake itself sits higher and in cleaner air. Dust is simply what you meet most often in this part of the world.
Ram head or cyclonic head?
A ram head raises and directs the intake. A cyclonic or pre-cleaner head spins the incoming air so centrifugal force throws dust and water out before it reaches the filter. For southern African gravel, where dust is the constant and water is occasional, the cyclonic head is usually the better choice.
Can I fit a snorkel myself?
You can, but the seal is the whole product. The joint into the airbox, the seal where the body is cut and the drain valve decide whether a snorkel works or is decorative, and the manufacturer's own installation guidance puts that responsibility on the installer. Our fitment centre partners do this every week.
Is a snorkel legal in South Africa?
Snorkels are fitted to 4x4s across the country as standard practice. Have yours fitted by a fitment centre that works to the manufacturer's instructions and the applicable regulations and safety standards, and you will not have a problem at a roadworthy.
